Electric Charging Station EVC Parking

EVC Parking

The PARKING EV charger excels in power and versatility. With alternating current (AC) capacities ranging from 22 kW to 88 kW, our EV charger stands out in the market for its unparalleled potency. Designed for public and commercial parking spaces, this station allows you to generate revenue from the first connection.

Thanks to its simplified installation and connection system, coupled with integrated features for management, accounting, and service billing, the PARKING EV charger offers a reliable and profitable source of additional income. Discover the perfect combination of performance and profitability with every charge.

Contact

EVC Parking

Contact

Specifications

Electrical

Maximum output AC power

22 – 88 kW

Network connector types

3P + N + PE (400 VAC +/- 10%; 50 Hz or 60 Hz)

Efficiency

100% (peak)

2 AC socket to choose

Type 1, Type 2, GB/T

Grounding system

IT, TT, TN-C-S

Charging protocols

Type 1: SAE J1772 North America, Japan, South Korea;
Type 2: Mennekes Europe; GB/T: China

Maximum AC output current

Type-1 AC cable 1 phase up to 8 kW
Type 2: AC outlet or 3-phase cable
GB/T 3-phase AC: up to 22 kW

Simultaneous charging

2 vehicles

Cable length to choose

2 m / 3 m / 4 m / 5 m / 6 m / 7 m / 10 m / 14 m

Energy metering

Built-in MID Meter Eichrecht / PTB compatible

Electromagnetic compatibility

EN 61000-6-3:2007; Conductive Interference Class A(B); Electromagnetic emission Class A(B)

Protection

Overcurrent, Overvoltage, Undervoltage, Ground fault, Direct current leakage

Warranty

5 years

Interface

Communication interface

WiFi / 3G / LTE / Ethernet, Modbus / M-Bus, USB port

Communication with control systems

OCPP 1.6/2.0 and OPC-UA

User interface

Capacitive anti-vandal display 10,1”; TFT LCD (IK8), touch control, multilingual interface

Authorization

Application / RFID / NFC / PIN code

Software update

Remote update via “NDGRID” web portal

Mechanical

Weight (Net)

70 kg

Dimensions H x W x D

1500 x 400 x 300 mm

Material to choose

Anti-vandal metal or heat resistant stainless steel

External influence

IP Rating

IP 54

Humidity

5% – 95%, non-condensing

Operating Temperature

-35°C – +55°C

See more See more See more Less Less Less

Connectors

Our Factory offers a wide range of connectors to meet the needs of all types of electric vehicles.

CCS1

CCS2

CHAdeMO

GB/T

AC Type 2

Individual Design

We welcome you to our exclusive EV charger customization service. Understanding your need for a unique design and distinctive style in all activities, we specialize in providing tailored customization to meet your exact requirements. We offer you an EV charger that is not only efficient and reliable but also designed for you in every detail.
